3月10日，第十七屆中國國際粉末冶金、硬質合金與先進陶瓷展（PM CHINA）在上海世博展覽館隆重開幕。北京三帝科技股份有限公司（以下簡稱“三帝科技”）攜BJ粘結劑噴射金屬/陶瓷及SLM梯度金屬3D打印解決方案參展。

圖：三帝科技現場展示BJ粘結劑噴射金屬打印機3DPTEK-J160R

展會同期，三帝科技在注射成形論壇上分享了《粘結劑噴射3D打印賦能粉末冶金》的主題報告。報告指出，傳統粉末注射成型（MIM）面臨前期投入高、開模成本高、產品尺寸受限等挑戰，而三帝科技通過粘結劑噴射3D打?。˙JM）技術實現了無模制造、復雜結構和大尺寸成型，為粉末冶金行業提供了更高效、低成本的解決方案。

BJ Binder Jet Metal/Ceramic Printing Solutions

三帝科技自主掌握BJ技術設備、材料、工藝等關鍵技術，在小粒徑粉體鋪放、粉床致密度提升、高尺寸精度控制、粘結劑材料體系開發、脫脂燒結工藝等方面具備成熟的技術和經驗。公司自主研制的3DPTEK-J160R/J400P/J800P系列化粘結劑噴射打印設備及其成型工藝，集成了精準供料系統、高致密鋪粉系統和高精度噴墨打印控制系統，解決了小粒徑低流動性粉末鋪放與成型致密度關鍵共性技術，突破了高分辨率、高精度噴墨控制關鍵技術，可實現800-1200dpi高分辨率打印成型，成型精度優于±0.1mm，成型效率最高可達3600cc/h，相關技術指標達到國際先進水平。

圖：BJ金屬/陶瓷打印機3DPTEK-J160R、3DPTEK-J400P/J800P

同時，三帝科技在多年BJ技術研究中逐步形成了健全的粘結劑材料成型工藝體系?；谒h(huán)保型粘結劑和溶劑基高效粘結劑兩大種類形成的20余種工藝配方，開發相應的成型工藝和脫脂燒結等后處理工藝，實現了適用于不銹鋼、工模具鋼、鈦合金、銅合金、高溫合金、硬質合金等金屬材料，碳化硅（SiC）等陶瓷材料以及PMX晶態蠟、無機鹽、食品、藥品、高分子復合材料等非金屬材料的成型工藝。同時，通過對高致密度脫脂燒結成型工藝的系統研究，實現了對脫脂燒結過程中金屬與陶瓷產品的控形與控性，對脫脂燒結后的成品質量實現精準把控，產品性能優于MIM國際材料標準的力學性能。

Figure: BJ Metal Printing

Figure: BJ Ceramic Printing

此外，三帝科技聯合深圳職業技術大學、深圳清華大學研究院、上海交通大學、北京科技大學等科研院所相關團隊共同開展粘結劑噴射成型等材料、工藝與應用的基礎技術研究，推動在工業模具、刀具、3C電子等產品，及復雜、異形大尺寸陶瓷產品等領域的產業化應用。

SLM激光金屬打印解決方案

三帝科技自主研發推出了SLM選區激光熔化金屬打印設備AFS-M120/M400、梯度金屬設備AFS-M120X(T)、多材料增減材設備AFS-M300XAS等，完成了不銹鋼/鈦合金/鋁合金/模具鋼/鈷鉻合金/鎳基合金等材料的成型及工藝開發。

圖：三帝科技SLM（梯度）金屬打印系列設備

其中，梯度金屬打印設備AFS-M120X(T)可適用于復合金屬材料的性能研究與開發，可實現兩種及以上多種金屬材料的連續梯度精確供粉；具備水平/垂直梯度變化方向，降低了工藝復雜性，節省粉末原材料、提升研發效率。在高通量材料制備、航空航天、汽車、醫療、模具加工等領域的新材料開發中具有廣闊的應用前景。多材料增減材梯度金屬AFS-M300XAS可適用于復合金屬材料的性能研究與開發，最多可實現4種材料的梯度，水平方向實現連續梯度變化，垂直方向實現材料成分切換或漸變。

目前，三帝科技已與北京科技大學、山東理工大學、蘭州理工大學、北京航空航天大學、北京鋼鐵研究總院、沈陽自動化所等眾多科研院所合作，不斷地提供先進、可靠、實用的梯度功能金屬材料解決方案。

了解更多3D打印賦能粉末冶金的解決方案，3月11-12日，上海世博展覽館三帝科技展位：H1館A735，歡迎蒞臨交流！

三帝科技登陸2025中國國際粉末冶金展最先出現在三帝科技股份有限公司。

2024 Innovative Technologies and Products for the Global Foundry Industry

2024 National Foundry Equipment Innovation Award

Award-winning products

Recently, Beijing 3DPTEK Technology Co.Ultra-large 3DP Sand Printer 3DPTEK-J4000Successful completion of installation and commissioning, in line with factory acceptance standards, will be delivered soon.

Figure: 3DPTEK-J4000 printing site

The equipment can effectively solve the efficiency and cost problems of large-size sand casting, providing a new solution for the industry. Traditional process in the production of large-size castings, usually need to split casting and then welding, increasing the design cost and time cost, but also prone to welding defects. 3DPTEK-J4000 adopts no sand box flexible area molding technology, support for local printing, the maximum can be molded 4 meters of the sand mold, can be completed in one piece of casting of large-size, complex structural parts, greatly improving production efficiency and casting quality, to meet the large size, high precision sand casting application needs. It can greatly improve production efficiency and casting quality, and meet the application requirements of large-size and high-precision sand castings.

In addition, the company also has 1.6 meters, 1.8 meters, 2.5 meters and other 3DP sand printer program to choose from, to meet the needs of different sizes of sand printing; at the same time to provide open source material process, can be adjusted for the user on demand; supporting the high-performance resin binder, curing agent, cleaning agent, to ensure that the molding quality and stability.

Equipment order hotline: 13811566237

3DPTEK-J4000 is especially suitable for large-size and batch casting manufacturing needs in aerospace, marine, electric energy, construction machinery, automotive (new energy) and other fields. In the aerospace field, it can be used to manufacture engine parts, spacecraft structural components, power units and other important parts, effectively solve the problem of molding oversized, multi-dimensional surfaces, complex structure of the workpiece, in the small batch of large-size mold manufacturing as well as special industry mold iterative upgrading of research and development on the traditional manufacturing process can not be compared with the advantages. In the field of electric power and energy, it can be used for the manufacture of large-size pressure-resistant complex cavity structure parts, large-size thin-walled lightweight parts and so on. In the automotive field, it can realize the manufacture of large-size thin-walled motor shells with complex spiral cooling waterways, lightweight frames, and complex internal cavity structure shell cylinder/cylinder head.

[About SANDI TECHNOLOGY

3D Printing Technology, Inc. is a 3D printing equipment and rapid manufacturing service provider, a national "specialization, specialization and innovation" small giant enterprise, the Ministry of Industry and Information Technology additive manufacturing typical application scenarios. At the same time has laser and binder jet 3D printing equipment and materials technology and application process, business covers 3D printing equipment, raw materials development and production, 3D printing process technology support services, metal parts rapid manufacturing services, etc., to establish a complete 3D printing additive manufacturing industry chain, widely used in aerospace, ships, pumps and valves, automotive, electric power and energy, industrial machinery, rail transportation, 3C, electronics, education and research, sculpture, culture and creativity, and so on. electronics, education and scientific research, sculpture and cultural creation, rehabilitation and medical industries.

震撼！三帝科技4米超大尺寸砂型打印機即將交付！最先出現在三帝科技股份有限公司。

Beijing SANDI Technology Co., Ltd. specializes in 3D printing equipment and additive manufacturing services, is theNational Specialized, Specialized and New "Small Giant" Enterprises, Typical Application Scenario Supplier of Additive Manufacturing of MIITTheIt also owns laser and binder jet 3D printing equipment and material technology and application process, and the product technology is mainly used to empower the casting industry and MIM industry. The business covers R&D and production of 3D printing equipment, R&D and production of 3D printing raw materials, and 3D printing process technology support services,Rapid Prototyping Servicesetc., has established a complete 3D printing rapid manufacturing industry chain.(Hotline: Manager Han 13811566237)

SANDI's self-developed industrial casting field for the3DP Inkjet Sand 3D Printer, SLS Selective Laser Sintering Sand/Wax 3D PrinterThe company is a blend of theNearly 30 years of experience in powder laying technologyThe company can meet the needs of manufacturing products of different sizes and materials.The

3DP Inkjet Sand 3D Printer

SANDI Technology 3DP inkjet sand 3D printer molding size, high printing efficiency, sand precision and strength than the traditional process, suitable for large size, complex structure, small and medium batch sand rapid manufacturing.

3DPTEK-J1600Pro

3DPTEK-J1600Plus

3DPTEK-J1800

3DPTEK-J2500

3DPTEK-J4000

Application Cases

SLS Selective Laser Sintered Sand 3D Printer

SANDI Technology SLS selective laser sintering sand 3D printer is suitable for one-piece molding of complex pipeline and oil pipeline structure sand mold. The precision of the printed sand mold can reach ±0.1mm and the strength can reach 4-6MPa.

LaserCore-5300

LaserCore-6000

Application Cases

SLS Selective Laser Sintering Wax 3D Printer

SANDI Technology SLS Selective Zone Laser Sintering Wax 3D Printer can rapidly mold large-size, thin-walled structure wax patterns with high molding precision and excellent surface quality.

LaserCore-5300

LaserCore-6000

Application Cases

SANDY Technology 3D printing technology empowers casting

Primary value:

1. Enhancement of new product development capabilities

-No need to open metal molds, reduce the cost of new product development and shorten the production cycle;

-Enhance the enterprise's ability to develop new products and new customers and grab orders for bulk orders.

2. Fast delivery of small quantities:

-Low-cost and high-efficiency production of small-lot products through 3D printing or a combination of 3D printing and traditional processes (outer mold: metal mold/wood mold; sand core: 3D printing).

3. Reduce process validation risk:

-Process validation before opening metal molds reduces risk of failure and mold repair time.

4. Rapid manufacturing of metal molds:

-Rapidly manufacture metal molds (aluminum molds, iron molds, etc.) through 3D casting process, which can shorten the manufacturing cycle of metal molds and reduce the manufacturing cost of 20% or more.

5. Optimize the process and improve the technical level:

-Satisfy the demand for lightweight, complex structural products, realize integrated molding, parts manufacturing into components manufacturing, help casting enterprises to enhance the level of technology, improve the added value of products, enhance the profitability of enterprises.

6. Improve material utilization:

-Improve casting material utilization and reduce resource consumption.

7. Enhance the corporate image and improve the production environment:

-Reduces labor intensity and eases recruitment challenges.

Collaborative Advantage:

1. The equipment is stable, reliable and proven in the market:With 30 years of experience in powder laying technology, the equipment is stable and reliable, and has been verified by the market that the 3D printers purchased by some users have been successfully and stably operated for more than 20 years;
2. At the same time, he has mastered the "3DP + SLS + BJ + SLM" process:It has the typical application scenario of additive manufacturing of the Ministry of Industry and Information Technology--"3DP+SLS" composite sand molding process;
3. Hands-on training, all inclusive:Provides comprehensive process guidance, equipment training, etc. through its multiple 3D manufacturing centers;
4. Nationwide after-sales service with timely response:Provides timely and nearby after-sales service through its multiple 3D manufacturing centers to ensure quick response;
5. Market synergy and resource sharing:Helping clients to expand their business opportunities and enhance their competitiveness in the market.

As a leader and application promoter of 3D printing technology, SANDY TECH.Has received investment support from well-known funds such as Jinke Junchuang, Zhongjin Capital, Zhongke Haichuang and Become Capital.The

Industry Applications

Hotline: Manager Han 13811566237

三帝科技3D鑄造解決方案，賦能鑄造產業提質增效最先出現在三帝科技股份有限公司。

Image from: Colibrium Additive / GKN Additive

International manufacturers are optimistic about the market potential of BJ technology and have entered the market.GE General Electric has been laying out BJ technology since 2016, after its Colibrium Additive launched the Series 3 metal binder jetting system. It cooperates with automobile manufacturers to produce lightweight and high-performance automotive parts and enhance the performance of the entire vehicle.HP HP launched HP Metal Jet technology in 2018 based on its thermal inkjet (TIJ) expertise and launched HP Metal Jet S100 metal printing solution four years later.GKN Additive adopts HP Metal Jet technology for automotive and industrial parts mass production, and MIM industry leader Parmatech uses HP Metal Jet technology for the manufacture of complex shaped precision surgical tools.

Figure: SANDY TECHNOLOGY BJ Metal/Ceramic Printer 3DPTEK-J160R, 3DPTEK-J400P/800P

As a large manufacturing country, China's market demand for BJ technology is more urgent. The leading domestic 3D printing equipment and rapid manufacturing service provider Beijing SANDI Technology Co., Ltd. independently masters the key technologies of BJ technology equipment, materials, processes, etc., and has mature technology and experience in small particle size powder placement, powder bed densification enhancement, high dimensional accuracy control, binder material system development, and degreasing sintering process. The company's self-developed 3DPTEK-J160R/J400P/J800P serialized binder jet printing equipment and its molding process integrates a precise feeding system, a high density powder laying system and a high-precision inkjet printing control system, which solves the key common technologies of small particle size and low mobility powder laying and molding density and breaks through the key technologies of high-resolution and high-precision inkjet control, and can realize 800-1200dpi high-resolution printing and molding, molding accuracy is better than ±0.1mm, molding efficiency up to 3600cc/h, the relevant technical indicators have reached the international advanced level.

Figure: BJ metal sample

SANDI Technology has gradually formed a sound binder material molding process system in years of BJ technology research. Based on more than 20 kinds of process formulas formed by two major types of water-based environmentally friendly binder and solvent-based high-efficiency binder, we have carried out systematic research and analysis on the physical and chemical properties of the binder and the interaction between the binder and the powder, and developed corresponding molding processes and post-processing processes such as degreasing and sintering, which have realized a complete and complete molding process applicable to stainless steel, tool steel, titanium alloys, copper alloys, high-temperature alloys, hard alloys and other metal materials, silicone carbide ( SiC) and other ceramic materials, as well as PMX crystalline wax, inorganic salts, food, pharmaceuticals, polymer composites and other non-metallic materials molding process. Meanwhile, through the systematic research on high density degreasing and sintering molding process, we have realized the shape and property control of metal and ceramic products in the process of degreasing and sintering, and realized the precise control of the quality of the finished products after degreasing and sintering, and the performance of the products is better than the mechanical properties of the MIM international material standard.

Figure: BJ ceramic sample

At the same time of realizing independent technological innovation, SANDI Technology gradually completes the construction of BJ standard manufacturing process, and establishes distributed printing service centers across the country to develop product manufacturing process based on BJ technology for customers, and promotes its application to the market. In addition, the company jointly with the Shenzhen Vocational and Technical University to build a joint laboratory of additive manufacturing technology, combined with Shenzhen Tsinghua University Research Institute, Shanghai Jiao Tong University, University of Science and Technology in Beijing and other research institutes and related teams to jointly carry out binder jet molding and other materials, process and application of basic technology research, and to promote the industrialization and application of the industrial molds, cutting tools, 3C electronic products, and complex, shaped and large-size ceramic products and other fields. Industrialization application.

In the field of 3C electronics, the market demand for increasingly diversified, complex and refined products has posed challenges to manufacturing technology, and traditional manufacturing technology has many limitations such as high manufacturing difficulty, low yield, high cost, etc., especially titanium alloys and other difficult-to-machine lightweight materials are even more difficult to realize. SANDI Technology has successfully broken through the traditional titanium alloy forming manufacturing technology barriers, based on BJ technology to achieve the rapid prototyping manufacturing of titanium alloy and other active metals, to realize the complex structure of 3C electronic product parts and components fast near-net shaping at the same time to simplify the manufacturing process and reduce the production and manufacturing costs.

Chart:Based on SANTI TechnologyautonomyBJskillfabrication(used form a nominal expression)Typical 3CProduct ComponentsMinimum structural scale 0.4mm, sintered densities better than 99%

In the field of food and drugs, in response to the growing demand for diversified, personalized and precise dietary markets, SANDI Technology, in conjunction with the Institute of Agricultural Products Processing of the Chinese Academy of Agricultural Sciences, carries out research on the adaptability of technology and equipment and equipment integration based on the self-developed BJ equipment, develops easy-to-swallow food made of food hydrogel and special shaped food made of food-based particles and carries out comprehensive evaluations of its safety and reliability. Comprehensive evaluation, and ultimately realize the industrialization demonstration application of personalized food additive manufacturing and intelligent processing equipment.

In the field of molds, for the problem of the difficulty of manufacturing molds with complex surfaces and fine texture structures, based on SANDI's BJ technology, it can realize the manufacturing of metal molds with high complexity and fineness in the scale range of 300mm×200mm×150mm, with the minimum texture expression scale of about 0.26-0.3mm, and at the same time, it breaks through the technology of sintering and densification of large-size atypical structural metal parts to realize At the same time, we have broken through the sintering densification technology for large-size non-typical structural metal parts, and realized the shape-controlled sintering with sintering performance meeting the requirements of practical applications.

With the continuous progress and innovation of technology, BJ technology is expected to play a more critical role in the future of industrial manufacturing, and its positive impact on manufacturing costs, efficiency and quality will certainly further promote this technology in 3C electronics, molds, automobiles, hardware, tools, cutting tools, medical equipment, sports equipment and other industries to form a hundred billion scale of industrialized applications.

[___About SANDI Technology]

3D Printing Technology, Inc. is a 3D printing equipment and rapid manufacturing service provider, a national "specialization, specialization and innovation" small giant enterprise, the Ministry of Industry and Information Technology additive manufacturing typical application scenarios supplier. At the same time has laser and binder jet 3D printing equipment and materials technology and application process, business covers 3D printing equipment, raw materials research and development and production, metal parts rapid manufacturing services, 3D printing process technology support services, etc., to establish a complete 3D printing additive manufacturing industry chain, widely used in aerospace, ship pumps and valves, automotive, energy power, industrial machinery, rail transportation, 3C, electronics, education and research, sculpture, culture and creativity. electronics, education and scientific research, sculpture and cultural creation, rehabilitation and medical industries.

BJ粘結劑噴射技術——驅動工業制造升級的新質生產力最先出現在三帝科技股份有限公司。

Green casting sand mold made by △3DP sand printing process

Huge base of industry scale

China as a global casting country, has a strong basic industrial volume, there are more than 24,000 casting enterprises, casting production accounted for the world 45%. According to the China Foundry Association data, in 2023, China's total output of all types of castings 51.9 million tons. Such a large industrial scale, the formation and development of foundry industry clusters provide a solid foundation, the agglomeration of many enterprises has produced economies of scale, reducing production costs and improving production efficiency.

Complete industry chain support

The casting industry has a long industrial chain, covering upstream raw material suppliers and equipment suppliers, midstream casting enterprises, and downstream numerous application fields. China's foundry industry cluster within the enterprise division of labor is clear, close collaboration, the formation of a complete industrial chain supporting. For example, in Henan and other places in the foundry industry cluster, not only a large number of foundry enterprises, and the provision of pig iron, scrap steel and other raw material suppliers, as well as the production of foundry machinery, machining equipment, testing equipment, this complete industrial chain makes the transaction costs between enterprises to reduce the shortening of the production cycle to respond quickly to the market demand, and enhance the overall competitiveness of the cluster.

Rich technical and human resources

After years of development, China's foundry industry cluster has accumulated a wealth of technology and human resources. On the one hand, the cluster enterprises in the long-term production practice of continuous exploration and innovation, the formation of their respective core technologies and techniques, such as some areas in the sand casting, precision casting, die casting and other areas with unique technical advantages; On the other hand, the cluster attracted a large number of professionals, including skilled workers, engineers, researchers and so on, they provide intellectual support for the enterprise's technological research and development and innovation. At the same time, the talent flow and technical exchanges between enterprises in the cluster are also more frequent, promoting the dissemination of technology and innovation, and is conducive to enhancing the technical level of the cluster as a whole.

Strong market radiation capability

China's casting industry cluster is widely distributed, and mostly concentrated in economically developed, convenient transportation areas, such as the Yangtze River Delta, the Pearl River Delta, etc. These areas have a superior geographic location and a good market environment, able to radiate the national and even global markets. The Yangtze River Delta casting industry cluster, for example, the production of castings not only to meet the domestic automobile, machinery and equipment industries such as a large number of needs, but also exported to Europe and the United States, Southeast Asia and other international markets, a strong market radiation capacity for the development of industrial clusters provides a broad space, prompting the enterprise to continue to expand the scale of production, improve product quality and market share.

Policy support and industry guidance

The state attaches great importance to the development of the foundry industry, the introduction of a series of related policies, such as the "14th Five-Year Plan" in the foundry industry digital transformation and development of clear goals, including the use of 3D printing technology by 2025 to produce more than 500,000 tons of castings, and so on. These policies provide strong support for the development of foundry industry clusters, guiding the development of industry clusters to high-end, intelligent, green direction, promoting the optimization and upgrading of industrial structure, and enhance the overall competitiveness of the cluster.

Regional brand effect

Some well-known foundry industry clusters have formed a regional brand effect, such as Botou's "China Foundry City", Jiaozuo's cylinder liner, "Henshan Casting", "Linzhou Casting" and so on. These regional brands have a high degree of visibility and reputation in the market, to attract more customers and resources for the cluster enterprises to bring more opportunities for development. At the same time, the construction of regional brands also prompted enterprises to pay more attention to product quality and brand image, strengthened cooperation and self-discipline among enterprises, and is conducive to maintaining the overall interests of the cluster and the market order.

China's foundry enterprises all over the world, forming a number of distinctive characteristics of China's manufacturing clusters. For example, in Henan Province, Xinxiang City has an annual output of 55,000 tons of large cast steel parts, with an export volume of more than 30%, Hui County has more than 100 casting enterprises, with a production capacity of more than 1.3 million tons; Pingdingshan Jiaxian is known as the capital of China's cast-iron pots ......

These clusters in the long-term development process, has accumulated a wealth of production experience and industrial resources, but at the same time also faced with the traditional casting process brought about by high energy consumption, high pollution and waste of resources and other issues. According to statistics, the traditional casting process in the material utilization rate there is greater room for improvement, and energy consumption intensity is higher, which not only increases the production cost of enterprises, but also on the environment has caused greater pressure, and China's dual-carbon goals to achieve a certain contradiction .

3D printing + casting new quality productivity

From the perspective of efficiency, pollution reduction and cost reduction, 3D printing + casting has green attributes and advanced nature:

improve efficiency

- Significantly shorten the production cycle: a company using "3D +" casting process, the production cycle shortened by 60% or more, such as core compressor cylinder production cycle shortened from 48 days to 12 days, the L-shaped bed shortened from 45 days to 15 days.

- Significant increase in capacity: "3D+" casting process capacity increase of 50%, doubling the efficiency, can quickly respond to market demand, improve the competitiveness of enterprises.

- Rapid prototyping: sand 3D printing technology can produce complex sand patterns in a short period of time, and quickly complete the production of prototype parts, such as a new energy vehicle enterprises trial production of water-cooled motor shells for commercial trucks, the use of 3DP sand printing delivered in 10 days, compared with the traditional process of 60 days of the production cycle has been shortened by 83%.

pollution reduction

- Material waste reduction: 3D printing on-demand manufacturing, support sand online recycling, sand utilization rate up to 95% or more, reducing the waste of raw materials in the traditional mold making process.

- Dust pollution reduction: SANDI technology sand 3D printing equipment in the production process can effectively reduce the generation of dust, with recycled sand and other environmentally friendly materials, help foundries to realize green manufacturing.

reduce costs

- Mould cost reduction: In traditional casting, the cost of instrument panel mould is 700,000-1,000,000 RMB, bumper mould is 350,000-700,000 RMB, and engine parts mould is 150,000-600,000 RMB or even higher, while 3D printing sand mould is low cost, flexible in design modification, and does not require expensive mould manufacturing cost.

- Reduced labor costs: The automation of the 3D printing process reduces the reliance on manual operation and human error, reducing labor costs, such as the 3D printing equipment of SANDI Technology can be operated with only simple training, without the need for a large number of manpower synergies.

- Reduced energy consumption: 3DP printing process 3D printing technology consumes less energy than sand core manufacturing and injection molding equipment. Compared with injection molding, 3DP printing sand molding is through the nozzle spray binder will sand bonding molding, without the need for injection molding like the material for a long time heating and melting and other processes, so the energy consumption is greatly reduced. Compared with 3DP printing sand mold, traditional sand core manufacturing in the hot core box method core, need to make the core box to keep at 200 ℃ -300 ℃, let the core sand shot into the core box, ammonium chloride in the higher temperature and the resin in the free formaldehyde reaction to generate acid, so that the core hardened very quickly, the process of energy consumption. While 3DP printing sand mold process, the sand does not need to be heated to such a high temperature, and the equipment itself is relatively low energy consumption.

△Green fast casting plant after upgrading 3DP sand printing process

SANTI Technology helps 3D casting

In this context.3D Printing Technology, Inc.The exploration and practice of the industry provides useful reference for the development of the industry. Three Emperor Technology has achieved remarkable results by acquiring six traditional foundries and introducing 3D printing technology to promote their transformation and upgrading. In the production process, the precise characteristics of 3D printing technology greatly improves the utilization rate of materials, effectively reduces the carbon emissions from the mining of raw materials to the processing of each link, reduces the impact on the environment, which is an important demonstration of China's foundry industry to reduce the intensity of resource consumption, improve the efficiency of resource utilization, and the relevant departments of the state to promote the green development of the industry, optimize the industrial structure of the policy direction of a high degree of compatibility.

Analyzed from the perspective of energy consumption, the repeated processing and correction processes in the traditional casting process lead to high energy consumption, while 3D printing-assisted casting simplifies the production process and reduces energy demand. The country has been committed to the reform and development of the energy sector, introduced a series of policy measures to improve energy efficiency and promote the application of clean energy. Foundry enterprises using 3D printing technology, can better synergize with these energy policies, such as the introduction of energy-saving 3D printing casting equipment, and combined with clean energy power supply, to further reduce carbon emissions, help the foundry industry green optimization of the energy structure, for the realization of the dual-carbon goals of total energy consumption and intensity of "double control" play a positive role. Role.

In the promotion of technological innovation, the development of China's manufacturing industry can not be separated from the depth of the application of emerging technologies in traditional industries and integration of innovation. State in the "14th Five-Year Plan" period, the Ministry of Industry and Information Technology and other departments have issued "on the promotion of casting and forging industry high-quality development of the guiding opinions" for the development of the industry to point out the direction of the industry, such as the promotion of intelligent transformation, to create intelligent manufacturing demonstration factories; to help the green development, adjusting the production capacity replacement policy; to support the development of high-quality enterprises, cultivate specialties, specialties, new "small giants" and manufacturing single champion; the development of industrial clusters, cultivate casting characteristics of industrial clusters and so on. For 3D printing + casting this innovative model, the relevant state departments attach great importance to the R & D investment, personnel training and technology promotion and other aspects of increasing policy support, continuation and deepening of the "14th Five-Year Plan" development strategy to the "15th Five-Year Plan" and beyond. Stage. Through the establishment of a special R & D fund to encourage universities, research institutions and enterprises to carry out in-depth cooperation between industry, academia and research, and jointly overcome technical problems, accelerate the maturity of green casting technology and application of popularization, enhance the overall technical level of China's foundry industry, enhance the low-carbon competitiveness in the international market, drive the high-quality development of industry with technological innovation, and to realize the transformation from a large casting country to a strong casting country, and specialize in specialties and special new technologies. The practical achievements of "small giants" SANDI Technology also provide a realistic reference for the precise implementation and optimization of the policy.

From the perspective of industrial cluster development, the relevant state departments can give full play to the advantages of China's manufacturing clusters to guide the establishment of 3D printing + casting green industrial park. Based on the foundry purchased by SanDi Technology and the industrial cluster where it is located, attract upstream and downstream related enterprises to move into the park, forming a complete green industry chain ecology. In the park, we centrally configure perfect infrastructure and environmental protection facilities, realize centralized waste treatment and recycling, and build a closed loop of green industry chain. Enterprises share 3D printing technology resources, energy management system, etc., can effectively reduce overall operating costs and carbon emissions, while facilitating the unified supervision and promotion of green casting standards, promote the green and low-carbon synergistic development of enterprises within the cluster, to become a demonstration sample of the green transformation of China's traditional foundry industry under the dual-carbon goal, to promote the comprehensive green change of the national foundry industry, and to realize the carbon peak and carbon neutrality goals for China. Carbon peak, carbon neutral target to provide solid industrial support and strong policy practice examples, and further highlight China's leading position in the field of global green manufacturing and the role of great powers.

3D打印+鑄造：驅動綠色鑄造變革，助力雙碳目標達成最先出現在三帝科技股份有限公司。

Recently, Yunnan South Asia Southeast Asia Security Research Center ("Yunnan South Asia Southeast Asia Security Research Center"), Yunnan Cross-border Data Technology Development Co,Beijing SANDI Technology Co.("SANDI") officially signed a strategic cooperation framework agreement on additive manufacturing foreign data security, the three parties will focus on Yunnan Dianzhong New Area in digital additive manufacturing, 3D printing foreign data, foreign data talent training and research, 3D printing foreign data security certification and other in-depth cooperation.

China has made remarkable progress in the field of additive manufacturing, especially in terms of exports, and has become one of the world's major suppliers of additive manufacturing products and services. However, with the development of technology and the intensification of international competition, foreign-related data security has become an important issue. In the context of globalization, countries need to protect key technologies and data security as well as promote international cooperation and technological innovation. By establishing multilateral mechanisms and international standards, cross-border data flows can be better managed to ensure the healthy development of additive manufacturing technologies.

The signing of the strategic cooperation between Yunnan South Asia Southeast Asia An Research Center, Yunnan Cross-border Digital Technology and SANTI Technology is an important initiative of the three parties to promote the development of Yunnan Province into a key node of China's radiation center facing South Asia Southeast Asia, an important economic driver for the construction of Yunnan Bridgehead, a model region for the experiment of the comprehensive construction of new urbanization in the western region and an advanced demonstration zone for reform and innovation, in accordance with the principles of complementarity of strengths and resources, synergistic development, and mutual benefit. It is an important initiative to develop Yunnan Province into a key node of China's radiation center facing South Asia and Southeast Asia, an important economic driving force for the construction of Yunnan Bridgehead, a model region for the comprehensive experiment on the construction of a new type of urbanization in the western region, and an early demonstration zone for reform and innovation.

Yunnan Security Research Center for South and Southeast Asia mainly carries out research on topics related to national security and overseas interest protection for South and Southeast Asia, analysis and research on security of security information technology products and systems, research on SWSJ security policies, standards, technologies and assessment methods, research and development of information technology and cybersecurity technologies, research and consulting services for planning industrial security projects and topics.

Based in Yunnan and facing the whole country, Yunnan Cross-border Data Technology Development Co., Ltd. is committed to promoting the development of foreign-related data security applications, and providing safe and efficient foreign-related data security services for the global operation of China's industries and enterprises, the national Belt and Road and the construction of Yunnan Digital Economy Demonstration Zone facing South Asia and Southeast Asia. By guaranteeing the safe implementation of the national strategy for South Asia and Southeast Asia, it realizes the effective protection of the overseas interests of the country, industries and enterprises.

Ltd. is a leading provider of 3D printing equipment and rapid manufacturing services, business covers 3D printing equipment, raw materials, R & D and production, rapid manufacturing services for finished metal parts, 3D printing process technology support services, etc., which are widely used in aerospace, ship pumps and valves, automotive, energy power, industrial machinery, rail transportation, 3C electronics, education and research, sculpture and cultural and creative, Rehabilitation and medical industries.

三帝科技與云南南亞東南亞安研中心、云南跨境數科達成增材制造涉外數據安全戰略合作最先出現在三帝科技股份有限公司。

Investment casting technologyNot only is it suitable for a wide range of casting metals, but it also demonstrates strong customization capabilities due to the flexibility of its wax modeling process, which further broadens the range of applications. InAerospace, manufacturing lightweight, high-precision parts to safeguard aircraft safety and performance; in theAutomotiveIn the field of industrial automation, it is used to manufacture key components of robots, precision instruments and equipment to ensure their performance and stability. In addition, the technology is also widely used in machinery manufacturing, energy power, rail transportation, sculpture, culture and creativity and other fields, for complex structures, large-size thin-walled products such as manufacturing.

However, this traditional process also faces the challenges of low productivity, high costs and high technical thresholds, especially in industries that require rapid market response or where cost control is particularly stringent.

Figure: SANDY TECHNOLOGY 3DP WAX PRINTER 3DPTEK-J400/J800

(hereinafter referred to as “3DPTEK”), a leading provider of 3D printing equipment and rapid manufacturing services in China, has independently developed and launched a series of 3DP wax printing equipment and material process, which is specially designed for industrial investment casting, and can realize low-cost and high-efficiency precision casting.

Based on the BJ binder jet molding technology, 3DP wax printing from 3DPTEK TECHNOLOGY can achieve processing speeds far exceeding those of laser molding, significantly shortening the processing cycle time and reducing material costs. At the same time, production efficiency is further enhanced by eliminating the need for mold opening and support structures. As a cold process molding technology, warping and deformation are effectively avoided during the molding process, reducing the complexity and time cost of subsequent processing.

Figure: 3DP Wax Mold Printing Precision Casting

3DPTEK 3DP wax printer 3DPTEK-J400/J800 has a molding accuracy of up to 800DPI and a minimum wall thickness of up to 1.5mm.The self-developed PMX crystalline wax material has a strong vanishing property and a very low ash content, which is extremely beneficial to the pouring process, and is able to significantly reduce the casting defects and enhance the yield rate, while at the same time reducing the pollution and realizing the green casting. It has already realized its application in the investment casting industry and shows great potential.

In the country vigorously advocate the casting industry to move towards digitalization, intelligence, green development, 3DP wax precision casting process is undoubtedly the emergence of those who are looking for technological innovation, transformation and upgrading of the traditional precision casting enterprises to provide a direction.

[About SANDI TECHNOLOGY

3D Printing Technology, Inc. is a 3D printing equipment and rapid manufacturing service provider, a national "specialization, specialization and innovation" small giant enterprise, the Ministry of Industry and Information Technology additive manufacturing typical application scenarios supplier. At the same time has laser and binder jet 3D printing equipment and materials technology and application process, business covers 3D printing equipment, raw materials research and development and production, metal parts rapid manufacturing services, 3D printing process technology support services, etc., to establish a complete 3D printing additive manufacturing industry chain, widely used in aerospace, ship pumps and valves, automotive, energy power, industrial machinery, rail transportation, 3C, electronics, education and research, sculpture, culture and creativity. electronics, education and scientific research, sculpture and cultural creation, rehabilitation and medical industries.

3D鑄造丨一種低本高效的熔模精密鑄造工藝最先出現在三帝科技股份有限公司。

SANDI is a leading provider of 3D printing equipment and rapid manufacturing services in China, a national "Specialized, Specialized, Specialized and New" small giant enterprise, and a typical application scenario supplier of additive manufacturing of the Ministry of Industry and Information Technology (MIIT). The company has laser and binder jet 3D printing equipment and materials technology and application process, business covers 3D printing equipment, raw materials research and development and production, rapid manufacturing services for finished metal parts, 3D printing process technology support services, etc., and has established a complete 3D printing rapid manufacturing industry chain. Our products and services are widely used in aerospace, automotive, energy and power, industrial machinery, ship pumps and valves, rail transportation, 3C electronics, education and research, sculpture and cultural creation, rehabilitation and medical industries.

Zhonghongtong is one of the leading enterprises in the high-voltage power transmission cast aluminum shell industry, national high-tech enterprise, provincial speciality enterprise, specializing in the research and development of large aluminum alloy castings and manufacturing, is an excellent supplier and long-term strategic partner of Pinggao Group, and is also the only supplier of GIS shells in China for South Korea LS, South Korea Nissin and so on. The company has strong independent research and development capabilities, with product design, mold design, casting process parameter design, core making, melting, casting, heat treatment, finishing, testing and product form test and other integrated production and processing capabilities, as well as the R & D and manufacturing capabilities of ultra-large shaped aluminum alloy castings, which can achieve an annual production capacity of 5,000 tons of high-end aluminum alloy parts for intelligent manufacturing. The core products are widely used in ultra-large voltage power transmission, rail transportation, aerospace, new energy and other fields. Among them, high-voltage power transmission cast aluminum products play an important role in famous power transmission projects at home and abroad, such as Baihetan Hydropower Station and ultra-high voltage power transmission network.

The strong combination of SANDI and Zhonghongtong not only combines SANDI's 3D digital technology advantages with Zhonghongtong's professional manufacturing capabilities in the field of high-voltage electrics, but also is a deep integration of the two sides in technological innovation and market expansion. Through this merger and acquisition, SANDI will be able to further expand its application in the field of high-voltage electrics, enhance the production and service capacity of large-size casting products, and at the same time will bring more powerful technical support and broader market prospects for Zhonghongtong.

Dr. Zong Guisheng, Chairman of SANDI Technology, said, "This acquisition is an important step in the strategic development of SANDI Technology, which not only provides a new growth point for our development in the field of high voltage electrics, but is also an important addition to SANDI Technology's 3D casting capability. Through the 3D casting centers in Pingdingshan, Henan, Xianyang, Shaanxi, Daming, Hebei, Rizhao, Shandong, Tongling, Anhui, and Yulin, Guangxi, we are able to better create value for our customers. We also look forward to the cooperation with Zhonghongtong to bring more innovations to both parties and jointly promote the industrialized application of 3D printing technology."

Qi Hongzhao, general manager of Zhonghongtong, also expressed positive confidence in the cooperation: "Through the cooperation with SANDI Technology, it enables us to take advantage of SANDI Technology's advanced technology and resources to further improve production efficiency, reduce production costs, improve product quality and yield, establish green, intelligent, high-end production and service capabilities, and expand Zhonghongtong's design and manufacturing capacity in high-end complex aluminum castings design and manufacturing capabilities in terms of aluminum castings, bringing more development opportunities for the company."

Nowadays, 3D casting solutions of SANDI Technology are continuing to empower various fields. In the aerospace field, 3D casting technology is used to manufacture engine parts, spacecraft structural parts, power units and other important parts, can effectively solve the oversized, multi-dimensional surfaces, complex structure of the workpiece molding problems in small quantities of large-size mold manufacturing as well as special industry mold iterative upgrading of research and development on the advantages of the traditional manufacturing process can not be compared. In the field of energy and power, 3D casting technology is used in the manufacture of large-size pressure-resistant complex cavity structure, large-size thin-walled lightweight parts. In the automotive field, 3D casting technology can be realized with a complex spiral cooling waterway large size thin-walled motor shell, lightweight frame, complex cavity structure shell cylinder/cylinder head and other products manufacturing.

三帝科技并購中宏通，加速布局3D鑄造在高壓電氣領域的應用最先出現在三帝科技股份有限公司。

          This project from the start to the design and development, and then to the installation and commissioning, each link has condensed the SANDI team's efforts and wisdom, showing the company's ultimate pursuit of quality. It is understood that at the beginning of the cooperation, SANDI Technology quickly responded to the customer's demand for printing large-size thin-walled cavity samples, only 13 hours to complete the printing, printing the completed samples of high precision, fine and clear surface texture, to obtain a high degree of customer recognition, and successfully reached the cooperation of the equipment. After the equipment design and production was completed, the professional technical team of SANDI went to Italy to complete the assembly and debugging, and provided professional technical training for the customer to help the customer quickly master the use of the equipment and maximize the value of the product.

          The SLS selective laser sintering 3D printer delivered this time is independently developed and produced based on the company's 30 years of experience in powder laying technology, and its performance and process are at the international leading level. The equipment integrates high-precision laser processing, dynamic focusing, precision motion control, etc. The printed sand pattern has high precision and strength, which is suitable for the manufacture of complex pipeline and oil pipeline structure products, and the printed wax pattern has high precision, which is suitable for the manufacture of thin-walled and complex structure products. This series of equipments are stable and reliable in operation and have been proven in the market for a long time. They have provided solutions for more than a hundred domestic and foreign customers and have been widely praised and recognized.

With the acceleration of globalization, SANDI Technology is accelerating the layout of overseas market as an important development direction. Relying on the synergistic innovation system of "National Thousand Science and Technology Research Institute, postdoctoral workstation and enterprise R&D team", the company has gathered several doctors and a team of foreign professionals to break through the key technology, optimize the product performance and improve the service system. At present, the product and service network of SANDI has covered the United States, Canada, France, Italy, Spain, New Zealand, Japan, South Korea, Singapore, Thailand, Vietnam, Saudi Arabia and other countries and regions, to provide excellent products and services to global customers with a global vision and international standards.
[About SANDI TECHNOLOGY

(3D Printing Technology, Inc.) is a leading provider of 3D printing equipment and rapid manufacturing services in China, a national "specialized, special and new" small giant enterprise, and a typical application scenario supplier of additive manufacturing of the Ministry of Industry and Information Technology. With the comprehensive capabilities of laser and binder jet 3D printing technology and material research and development, equipment manufacturing, finished metal parts manufacturing and process technology support, the company has established a complete 3D printing rapid manufacturing industry chain. Its products and services are widely used in many fields such as aerospace, automotive, energy power, ship pump valve, industrial machinery, sculpture and cultural creation.

筑基海外新里程：三帝科技SLS鑄造蠟型3D打印機成功交付意大利客戶最先出現在三帝科技股份有限公司。

Recently, the China Machinery Industry Federation (CMIF) and the Chinese Society of Mechanical Engineering (CSME) announced the2024 Machinery Industry Science and Technology Award WinnersThe University of Science and Technology Beijing, together with Beijing SANDI Technology Co. (hereinafter referred to as "SANDI"), jointly declared by the University of Science and Technology Beijing and Beijing SANDI Technology Co.High Efficiency Preparation Technology and Equipment for SLM Materials Based on Gradient Powder SpreadingProject, honored withSecond Prize of "Machinery Industry Science and Technology Award"The members of the project team areZhang Baicheng, Qu Xuanhui, Chen Qingwen, Zhang Lin, Wen Yaojie, Liu MinThe

The Machinery Industry Science and Technology Award is a comprehensive science and technology award in the national machinery industry jointly established by the China Machinery Industry Federation and the Chinese Society of Mechanical Engineering and approved by the Ministry of Science and Technology of the People's Republic of China.In the year of 2024, a total of 430 projects were awarded with "Machinery Industry Science and Technology Award", among which, 5 projects were awarded with the Grand Prize, 40 projects with the First Prize, 197 projects with the Second Prize and 188 projects with the Third Prize. This award is a full affirmation and recognition of the company's scientific and technological innovation ability.

Figure: Gradient Metal Parts 316L-CuSn10; 1.2709-316L

The award-winning program presents "High-efficiency preparation of SLM materials based on gradient spreading of powder"New ideas, developedHigh-efficiency preparation of multi-phase continuous gradient SLM materials, realizing stable layup of two/multi-phase full-scale continuous gradient powder layers, which helps to enhance the technological level of efficient material preparation in China.

As a leading domestic3D Printing Equipment and Additive Manufacturing Service ProviderSANDI Technology has independently developed the gradient metalAFS-M120X(T)Multi-material gradient metal with increase or decrease in materialAFS-M300XASetc.; in which multi-material increase/decrease material gradient metalAFS-M300XASsuitable forResearch and development of properties of composite metal materials with gradients of up to four materials, continuous gradient changes in the horizontal direction, and material composition switching or gradient changes in the vertical direction.It lowers the threshold of gradient composite material preparation process, reduces the loss of powder raw materials and improves the efficiency of research and development. It has a broad application prospect in the development of new materials in high throughput material preparation, aerospace, automotive, medical, mold processing and other fields. At present, SANDI has cooperated with many research institutes such as University of Science and Technology Beijing, Shandong University of Science and Technology, Lanzhou University of Science and Technology, Huazhong University of Science and Technology, Beijing University of Aeronautics and Astronautics, Beijing Iron and Steel Research Institute, Shenyang Institute of Automation, etc., to continuously provide advanced, reliable and practical solutions for gradient functional metal materials.

[About SANDI TECHNOLOGY

3D Printing Technology, Inc. is a 3D printing equipment and rapid manufacturing service provider, a national "specialization, specialization and innovation" small giant enterprise, the Ministry of Industry and Information Technology additive manufacturing typical application scenarios supplier. At the same time has laser and binder jet 3D printing equipment and materials technology and application process, business covers 3D printing equipment, raw materials research and development and production, metal parts rapid manufacturing services, 3D printing process technology support services, etc., to establish a complete 3D printing additive manufacturing industry chain, widely used in aerospace, ship pumps and valves, automotive, energy power, industrial machinery, rail transportation, 3C, electronics, education and research, sculpture, culture and creativity. electronics, education and scientific research, sculpture and cultural creation, rehabilitation and medical industries.

2024機械工業科學技術獎榜單發布，三帝科技榮譽上榜！最先出現在三帝科技股份有限公司。
